9-14 Maintaining the MultiPASS C3000 Chapter 9
Replacing a BJ Tank in the BC-21 Color
BJ Cartridge
If you perform a print operation correctly but the output is blank,
portions are missing, or colors are very wrong, a BJ tank may be out
of ink. If the output is still blank after cleaning the print head at least
five consecutive times, replace the empty BJ tank in the BC-21 Color
BJ cartridge.
You leave the BJ cartridge in the MultiPASS C3000 when replacing a
BJ tank.
The cartridge holder then moves to the
center of the unit.
❍ Grasp both sides and lift it up.
C
Do not try to move the cartridge holder manually, or you may damage
the unit. If the cartridge holder does not move and the unit beeps
several times, unplug the MultiPASS C3000 and let it cool for several
minutes. (The device has an automatic protection mode that prevents it
from overheating.) After allowing it to cool, plug the unit in again and
press the
CARTRIDGE
button to move the cartridge holder to the center
Open the
printer cover.
2
Press the
CARTRIDGE
button.
1
MPC-3000—USERS MANUAL/V000/07-97
CO
VER_OPEN(A)
DO NOT TOUCH THE
ROUND SHAFT
DO NOT TOUCH THE
RIBBON CABLE
DO NOT TOUCH THE
GUIDE RAIL
