Chapter 9 Maintaining the MultiPASS C3000 9-13
❍ The BJ cartridge locks into position.
❍ Do not apply excessive force.
The MultiPASS C3000 cleans the print head
and moves the cartridge holder to the home
position on the right side of the unit.
Close the
printer cover,
and press the
CARTRIDGE
button.
9
Ink Cartridge BCl-21
Color
Made in Japan Ink Cartridge BCl-21
Black
Made in Japan
Make sure the
cartridge is
aligned against
the back of the
holder, then
lower the green
lock lever.
8
MPC-3000—USERS MANUAL/V000/07-97
Maintaining the
MultiP
ASS C3000
LEVER_DN
