C-PRO MICRO SAVE APPLICATION MANUAL

Page 47

8

MODBUS VARIABLES


The controller can be managed by a supervisor via Modbus protocol. The communication takes
place via optional TTL/RS485 serial interface outside the controller. The various states/parameters
exported from the controller are shown below.

8.1

ModBus exporting table

Addr

Base 0

Addr

Base

1

Name

Value

Min

Max

Description

Mode

0x0100

257

Packed_DI

0

0

65535

Bit1=DI1, Bit2=DI2,
Bit3=DI3, ...,
Bit13=DI13,
Bit14=DI14

R/W

0x0180

385

Packed_DO

0

0

65535

Bit1=DO1,
Bit2=DO2, ...,
Bit13=DO13,
Bit14=DO14

R/W

0x0200

513

AI01_Antireeze_Probe

0.0

-3276.8

3276.7

R/O

0x0201

514

AI02_AirSupply_Probe

0.0

-3276.8

3276.7

R/O

0x0202

515

AI03_AirReturn_Probe

0.0

-3276.8

3276.7

R/O

0x0203

516

AI04_CO2_Probe

0

-32768

32767

R/O

0x0204

517

AI05_AirExternal_Probe

0.0

-3276.8

3276.7

Only Complete
Version

R/O

0x0281

642

AO_ByPassRecover

0.00

0.00

100.00

R/W

0x0282

643

inverterFan_Return

0.00

0.00

100.00

R/W

0x0283

644

inverterFan_Supply

0.00

0.00

100.00

R/W

0x0284

645

AO_HeatingCoilRequest

0.00

0.00

100.00

Only Complete
Version

R/W

0x0300

769

PackedAlarm_1

0

0

65535

Bit1=AL01,
Bit2=AL02,
Bit3=AL03,
Bit4=AL04,
Bit5=AL05,
Bit6=AL06,
Bit7=AL07,
Bit8=free,
Bit9=AL09,
Bit10=AL10,
Bit11=AL11,
Bit12=AL12,
Bit13=AL13,
Bit14=AL14,
Bit15=AL15,
Bit16=AL16

R/W

0x0301

770

PackedAlarm_2

0

0

65535

Bit1=AL17,
Bit2=AL18,
Bit3=AL19,

R/W
