C-PRO MICRO SAVE APPLICATION MANUAL
Page 14
Connector 3: Connector for the analogue output (optional, not available in the day versions)
Conn. Code Description (Version V+I)
C3-1 AO2 0-10VDC
C3-2 GND Common analogue output
C3-3 AO3 4-20mA
Description (Version I+I)
C3-1 AO2 4-20mA
C3-2 GND Common analogue output
C3-3 AO3 4-20mA
Description (Version V+V)
C3-1 AO2 0-10VDC
C3-2 GND Common analogue output
C3-3 AO3 0-10Vdc
Connector 4: Connector for low voltage signals
Conn. Code Description
C4-1 12VAC Power supply (12VAC/DC)
C4-2 5V Ratiometric transducers power supply
C4-3 GND Common analogue and digital inputs
C4-4 GND Common analogue and digital inputs
C4-5 AI4 Analogue input n.4
(for NTC probes, 0/4-20 mA or 0-5V transducers)
C4-6 AI3 Analogue input n.3
(for NTC probes, 0/4-20 mA or 0-5V transducers)
C4-7 AI2 Analogue input n.2 (for NTC probes)
C4-8 AI1 Analogue input n.1 (for NTC probes)
C4-9 12VAC Power supply (12VAC/DC)
(max. 50 mA, not protected against short circuit)
C4-10 12VDC 0/4-20 mA transducers and phase cut module power supply
C4-11 AO1 Jog output for phase cut module
C4-12 DI5 Digital input n.5
C4-13 DI4 Digital input n.4
C4-14 DI3 Digital input n.3
C4-15 DI2 Digital input n.2
C4-16 DI1 Digital input n.1
Connector 5: Connector for the remote keyboard and expansion of I/O (CAN)
Conn. Code Description
C5-1 CAN + Connector for the connection of the CAN + serial port
C5-2 GND Ground reference connector
C5-3 CAN - Connector for the connection of the CAN - serial port
