Fireside Inspection - Continued
Figure 6-4. Innovation Heater – Partial Left-Side View
PARTIAL RIGHT-SIDE VIEW WITH SUPPORT REMOVED
Figure 6-5. Innovation Heater – Partial Cut-Away View
BURNER
ASSEMBLY
46023
INTAKE
MANIFOLD
44106
CONDENSATE
SHIELD
49209
BURNER GASKET
18899
FIBER FRAX GASKET
124749
EXHAUST
MANIFOLD
5/16-18 STUDS
(6)
SIDE NUTS (2)
FRONT NUT
(1)
EXHAUST SENSOR
