Page 107
Innovation Water Heaters Installation, Operation & Maintenance Manual
CHAPTER 8 – RS232 COMMUNICATION
OMM-0078_0J
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
Page 107 of
196
GF-128
Phone: 800-526-0288
PRI: 11/22/2013
Table 8-1. Sample Fault Log Display
No.
Fault Message
Cycle Date
Time
0
Direct Drive Signal Fault
609 1/10/02
8:42am
1
Low Gas Pressure
366 7/04/01
5:29pm
2
Loss of Power
0 1/01/01
11:50am
8.4.2 Operation Time Log
The Operation Time Log consists of a string of ASCII records stored in non-volatile memory
within the C-More Control Panel. Events such as power-up, ignition and turn-off are time
stamped. Data logged while the unit is running are run-length encoded. Data is logged or the
run-length incremented every 30 seconds. For a new run record to be logged, the fire rate or
flame strength must change by more than 5%, or the run mode must change. At steady-state,
the run-length is allowed to reach a maximum of 30 minutes before the record is logged. This
means that no more than 30 minutes of data can be lost if the unit loses power. Table 8-2 shows
a sample Operation Time Log for a unit:
Table 8-2. Sample Operation Time Log Display
Status
Fire Rate
Flame
Run Length Date
Time
Off, Direct Drive
0
0
8
1/15/02
2:35pm
Run, Direct Drive
38
100
34
1/15/02
2:27pm
Run, Direct Drive
31
100
30
1/15/02
1:53am
Run, Direct Drive
35
100
2
1/15/02
1:23pm
Run, Direct Drive
29
100
0
1/15/02
1:21pm
Ignition
0
0
0
1/15/02
1:20pm
Off, Switch
0
0
35
1/15/02
12:30pm
Run, Manual
40
100
0
1/15/02
11:55am
Ignition
0
0
0
1/15/02
11:55am
Power-up
0
0
0
1/15/02
11:50am
The Operation Time Log can only be accessed through the RS232 interface using a laptop or
other terminal device. Ten operation time records are displayed for each T command entry. The
operation time log can be cleared ONLY by factory authorized personnel using the Clear Log
option in the Factory menu.
NOTE
The Sensor (S) Log can store up to 1200 records. Therefore, to view the
most recently logged record, enter “S” followed by 0 (zero) and then press
Enter (i.e. S0
order, enter S and press Enter. To go back 200 or 700 records, enter S200
or S700, etc. and press Enter.
8.4.3 Sensor Log
The sensor values can be logged at a different rate if needed by setting the Sensor Log Interval in
the Diagnostics Menu. The log interval can vary from once every minute to once every day.
