AERCO Innovation (G-13-1854 and above) User Manual
Page 100
Innovation Water Heaters Installation, Operation & Maintenance Manual
CHAPTER 7 – TROUBLESHOOTING GUIDE
Page 100 of
196
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
OMM-0078_0J
PRI: 11/22/2013
Phone: 800-526-0288
GF-128
Figure 7-1. Gas Train Component Locations
Figure 7-2. Blower-Side Intake Manifold (Shown removed from Heater)
MANUAL
SHUTOFF
VALVE
SSOV
LEAK
DETECTION
BALL VALVE
TO AIR/FUEL
VALVE
LOW GAS
PRESSURE SWITCH
HIGH GAS PRESSURE
SWITCH
GAS INLET
FLAME
DETECTOR
BLOWER SIDE
INTAKE
MANIFOLD
IGNITOR
FLAME
DETECTOR
FLAME DETECTOR
GASKET
BURNER FLANGE
GASKET
OBSERVATION
PORT
IGNITOR
