Innovation Water Heaters Installation, Operation & Maintenance Manual
CHAPTER 7 – TROUBLESHOOTING GUIDE
OMM-0078_0J
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
Page 101 of
196
GF-128
Phone: 800-526-0288
PRI: 11/22/2013
Figure 7-3. SSOV Actuator With Gas Pressure Adjustment & Damping Orifice
SSOV ACTUATOR
COVER
ACTUATOR
COVER SCREW
DAMPING
ORFICE
BRASS HEX HEAD CAP
(Remove to access gas
pressure adjustment screw)
OPEN/CLOSED
INDICATOR WINDOW
