Innovation Water Heaters Installation, Operation & Maintenance Manual
CHAPTER 3 – OPERATION
Page 48 of
196 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
OMM-0078_0J
PRI: 11/22/2013
Phone: 800-526-0288
GF-128
3.10 START/STOP LEVELS
The start and stop levels are the Air/Fuel Valve positions (% open) that start and stop the unit,
based on load. These levels are Factory preset as follows:
Start Level: 25%
Stop Level: 16%
Normally, these settings should not require adjustment.
Note that the energy input is not linearly related to the Air/Fuel Valve position. Refer to Table 3-
7 for the relationship between the energy input and Air/Fuel Valve position for a unit running on
natural gas.
Table 3-7. Relationship Between Air/Fuel Valve Position and Energy Input
For Units Running Natural Gas
Air/Fuel Valve
Position (%
Open)
Innovation Water Heater Model: Energy Input (BTU/Hr.)
INN600 INN800 INN1060 INN1350
16% 45,000 45,000 45,000 45,000
20% 87,000 97,000 97,000 181,000
30% 174,000 192,000 222,000 370,000
40% 243,000 330,000 416,000 665,000
50% 306,000 424,000 520,000 870,000
60% 370,000 486,000 715,000 1,001,000
80% 483,000 615,000 845,000 1,203,000
100% 600,000 800,000 1,060,000 1,350,000
