AERCO Innovation (G-13-1854 and above) - Manual (Page 36)

Innovation Water Heaters Installation, Operation & Maintenance Manual
CHAPTER 3 – OPERATION
Page 36 of
196 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
OMM-0078_0J
PRI: 11/22/2013
Phone: 800-526-0288
GF-128
Figure 3-1. Control Panel Front View
*NOTE
If there is a requirement to use the RS232 port (Item 4) on the C-
More controller front panel, contact AERCO to purchase the
RS232 Adaptor Cable (P/N 124675), which is designed for this
purpose. This cable features a DB9 connector for connection to
older computers with serial ports or can be used with a Serial-to-
USB adaptor for use in modern computer USB ports.
3
2
1
*4
5
7
8
9
10
11
12
6
