Innovation Water Heaters Installation, Operation & Maintenance Manual
APPENDIX A – INNOVATION MENU ITEM DESCRIPTIONS
Page 122 of
196 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
OMM-0078_0J
PRI: 11/22/2013
Phone: 800-526-0288
GF-128
INNOVATION MENU ITEM DESCRIPTIONS – Continued
MENU LEVEL & OPTION DESCRIPTION
CONFIGURATION MENU
Internal Setpoint Allows internal setpoint to be set . (Default = 130°F)
Unit Type Allows selection of KC Boiler, KC Boiler LN, BMK Boiler,
BMK Boiler LN, BMK Boiler Dual, KC Water Heater, KC
Water Heater LN, Water Heater 2010
Unit Size Sets unit size from 0.5 to 6.0 MBTUs. (Default = 1.0 MBTU)
Fuel Type Allows selection of Natural Gas or Propane.
(Default = Natural Gas)
Heater Mode It allows selection of: Constant Setpoint, or Remote
Setpoint. (Default = Constant Setpoint Mode)
Remote Signal Used to set the type of external signal which will be used
when operating in the Remote Setpoint Mode.
(Default = 4-20 mA/1-5V)
Outdoor Sensor Allows outdoor sensor function to be enabled or disabled.
(Default = disabled.)
Setpoint Lo Limit Used to set the minimum allowable setpoint (40°F to
Setpoint Hi Limit). (Default = 60°F)
Setpoint Hi Limit Used to set the maximum allowable setpoint (Setpoint Lo
Limit to 240°F). (Default = 200°F)
Temp Hi Limit This is the maximum allowable outlet temperature (40 to
240°F). Any temperature above this setting will turn off the
unit. The temperature must then drop 5°F below this setting
to allow the unit to run. (Default = 160°F)
Max Valve Position Sets the maximum allowable valve position for the unit (40%
to 100%). (Default = 100%)
Pump Delay Timer Specifies the amount of time (0 to 30 min.) to keep the pump
running after the unit turns off. (Default = zero)
Aux Start On Dly Specifies the amount of time to wait (0 to 120 sec.) between
activating the Aux Relay (due to a demand) and checking
the pre-purge string to start the heater. (Default = 0 sec)
Failsafe Mode Allows the Failsafe mode to be set to either Constant
Setpoint or Shutdown. (Default = Shutdown)
Analog Output Must be set to Valve Pos 0-10V.
Lo Fire Timer Specifies how long (2 to 600 sec.) to remain in the low fire
position after ignition, before going to the desired output.
(Default = 2 sec)
Network Timeout Specifies the timeout value (seconds) before a Modbus fault
is declared. Available settings range from 5 to 999 seconds.
(Default = 30 seconds)
HI DB Setpt EN Operating at a Valve Position below this value will inhibit the
DEADBAND feature. When operating at a Valve Position
below this value, the effective Setpoint is equal to Active
Setpoint + DEADBAND HIGH.
Setting range is from 0 to 100. (Default = 30)
