3.4 OPERATING MENU
The Operating Menu displays a number of key operating parameters for the unit as listed in
Table 3-2. This menu is “Read-Only” and does not allow personnel to change or adjust any
displayed items. Since this menu is “Read-Only”, it can be viewed at any time without entering a
password. Pressing the
▲ arrow key to display the menu items in the order listed (Top-Down).
Pressing the
▼ arrow key will display the menu items in reverse order (Bottom-Up).
Table 3-2. Operating Menu
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Active Setpoint 40°F 240°F
Inlet Temp 40°F 140°F
Air Temp -70°F 245°F
Outdoor Temp* -70°F 130°F
Valve Position In 0% 100%
Valve Position Out 0% 100%
FFWD Temp 80°F 160°F
Flame Strength 0% 100%
Run Cycles 0 999,999,999
Run Hours 0 999,999,999
Fault Log 0 19 0
NOTE
The Outdoor Temp display item shown with an asterisk in Table 3-2 will not
be displayed unless the Outdoor Sensor function has been enabled in the
Configuration Menu (Table 3-4).
3.5 SETUP MENU
The Setup Menu (Table 3-3) permits the operator to enter the unit password (159) which is
required to change the menu options. To prevent unauthorized use, the password will time-out
after 1 hour. Therefore, the correct password must be reentered when required. In addition to
permitting password entries, the Setup Menu is also used to enter date and time, units of
temperature measurements and entries required for external communication and control of the
unit via the RS-232 port. A view-only software version display is also provided to indicate the
current Control Box software version.
