AERCO Innovation (G-13-1854 and above) - Manual (Page 138)

Innovation Water Heaters Installation, Operation & Maintenance Manual
APPENDIX F – PARTS LIST DRAWINGS
Page 138 of 196 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0078_0J
PRI: 11/22/2013 Phone: 800-526-0288 GF-128
Innovation 600/800/1060/1350 Parts List – Continued
Item Qty
Part
Number Description
73 3 52030 STUD: 5/8/-11 UNC X 7 3/4" LONG [PLATED]
74 1 59039 6" WORM-DRIVE HOSE CLAMP
75 1 39125 ADAPTER: AIR INLET 6" PVC
76 1 62005 CORD GRIP
78  1 61034 AC CURRENT TRANSDUCER
80 1 90083-2.00 NIPPLE S/S: 1/8 NPT X 2 LG
81 1 93410 COUPLING: 1/8 NPT 304 SST 150PSI
82 1 93357 PLUG: 1/8 NPT HEX PIPE 304 STAINLESS
83 1 80088 EXHAUST MANIFOLD SEAL
PARTS FOR MODELS EQUIPED WITH ACTUATOR/SEQUENCING VALVE
98
1 93100 UNION: 2" NPT 304 STAINLESS
99 1 90046-3 NIPPLE: 2" NPT 304 SS
100 1 92093 VALVE: 2" DOMESTIC WATER MTRZD SEQ BALL
NOTES:
 Not shown in drawings below
 For pictorial purposes only. See below for full gas train full diagrams and part lists.
 See drawing PL-A-164 below for exploded diagram and full part list.
 24311-3 A/F VALVE FRU KIT
1 81057 GASKET: BLOWER
1 88003 O-RING #2-339
1 24220-3 A/F VALVE ASSY
 58039 BLOWER FRU KIT
1 24111 BLOWER: AMETEK 8.9"
1 81064 GASKET: BLOWER
1 81057 GASKET: BLOWER
 69126 LWCO/CAPACITOR ASSEMBLY KIT
1 122843 LOW WATER CUT-OFF
1 63070 47 MCF CAPACITOR ASSY
1 122690 NUT, ACORN NYLON #8-32
 24335-1 LOW NOx BURNER ASSY REPLACEMENT KIT
1 46023 BURNER HEAD ASSEEMBLY
1 GP-18899 BURNER FLANGE GASKET
1 124749 FIBER FRAX GASKET
 24336-TAB PLATED HEAT EXCHANGER KIT
AERCO
International, Inc.
Blauvelt, NY 10913
Innovation Parts List 09/15/2013
29184-TAB rev G, 29293 rev D Page 2 of 4
