AERCO Innovation (G-13-1854 and above) - Manual (Page 44)

Innovation Water Heaters Installation, Operation & Maintenance Manual
CHAPTER 3 – OPERATION
Page 44 of
196 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
OMM-0078_0J
PRI: 11/22/2013
Phone: 800-526-0288
GF-128
Table 3-5. WHM Menu
Available Choices or Limits
Menu Item
Display
Minimum Maximum Default
WHM Mode Off, WHM Slave,
WHM Master
Off
WHM Setpoint 40°F 200°F 130°F
WHM Nxt On FR 16% 100% 75%
WHM Nxt Off FR 16% 100% 35%
Lead/Lag Hours 25 225 72
Setback Setpoint 40°F 220°F 130°F
Setback Start 12:00am 11:59pm 12:00am
Setback End 12:00am 11:59pm 12:00am
*WHM Auto Mstr Yes or No No
*WHM Auto Timer 10 sec. 120 sec. 30 sec.
*NOTE
The Level 2 Password (6817) in the Setup Menu must be entered to view
or change the WHM Auto Mstr and WHM Auto Timer options.
3.8 TUNING MENU
The Tuning Menu items in Table 3-6 are Factory set for each individual unit. Do not change
these menu entries unless specifically requested to do so by Factory-Trained personnel.
Table 3-6. Tuning Menu
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Prop Band 1°F 120°F 8°F
Integral Gain 0.00 2.00 1.6
Derivative Time 0.0 min 2.00 min 0.10 min
Reset Defaults? Yes, No, Are You Sure? No
