Benchmark 6000 DF Installation, Operation & Maintenance Manual
CHAPTER 3 – OPERATION
OMM-0096_0B AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 45 of 219
GF-141
Ph.: 800-526-0288
03/21/2014
Table 3-4: Configuration Menu
Menu Item Display
Available Choices or Limits
Default
Minimum Maximum
Internal Setpt Lo Temp Limit Hi Temp Limit 130°F
Unit Type KC Boiler, KC Boiler LN,
BMK Blr Std, BMK Blr Std Dual,
BMK Blr LN, BMK Blr LN Dual
KC Water Heater,
KC Water Heater LN,
Innovation WH
BMK Boiler LN
Unit Size
(Only the unit sizes
available for the Unit
Type will be displayed) 750 MBH, 1000 MBH,
1500 MBH, 2000 MBH,
2500 MBH, 3000 MBH,
6000 MBH
6000 MBH
Fuel Type Natural Gas or Propane Natural Gas
Boiler Mode Constant Setpoint,
Remote Setpoint,
Direct Drive,
Combination,
Outdoor Reset
Constant
Setpoint
Remote Signal
(If Mode = Remote
Setpoint, Direct Drive
or Combination)
4 – 20 mA/1 – 5V
0 -20 mA/0 – 5V
PWM Input (Legacy BMS ), Network
4 – 20 mA,
1-5V
Outdoor Sensor Enabled or Disabled Disabled
*Bldg Ref Temp
(If Mode = Outdoor
Reset) 40°F 230°F 70°F
*Reset Ratio
(If Mode = Outdoor
Reset) 0.1 9.9 1.2
*System Start Tmp
(If Outdoor Sensor =
Enabled) 30°F 100°F 60°F
Setpt Lo Limit 40°F Setpt Hi Limit 60°F
Setpt Hi Limit Setpt Lo Limit 210°F 140°F
Temp Hi Limit 40°F 210°F 160°F
*NOTE
The Bldg Ref Temp and Reset Ratio Menu Items are only displayed when
the Outdoor Sensor is set to “Enabled”.
