Benchmark 6000 DF Installation, Operation & Maintenance Manual
CHAPTER 7 – MAINTENANCE
OMM-0096_0B AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 111 of 219
GF-141
Ph.: 800-526-0288
03/21/2014
Rear Refractory Replacement Procedure – Continued
Figure 7-7. Partial Rear View Showing Rear Plate
Figure 7-8. Partial Rear View With Rear Plate Removed
THERMAL SWITCH
O
2
SENSOR
GAS SUCTION
LINE
from EXHAUST
MANIFOLD
REAR PLATE
METAL TABS
(4 EACH)
REFRACTORY
REFLECTOR
