Figure k-2: benchmark control panel rear view – AERCO BMK 6000 Dual Fuel User Manual
Page 208
Benchmark 6000 DF Installation, Operation & Maintenance Manual
APPENDIX K – C-MORE CONTROL PANEL VIEWS
Page 208 of 219
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
OMM-0096_0B
03/21/2014
Ph.: 800-526-0288
GF-141
P
1
P
2
P
3
P
4
P
5
P
6
SHELL HARNESS
CONNECTOR
(19 PIN)
GAS TRAIN HARNESS
CONNECTOR
(9 PIN)
A/F VALVE HARNESS
CONNECTOR
(16 PIN)
SENSOR
HARNESS
CONNECTOR
(7 PIN)
INTERLOCK HARNESS
CONNECTOR
(16 PIN)
TO INPUT/OUTPUT (I/O)
BOX
EXT. SENSOR/COMM
HARNESS CONNECTOR
(24 PIN)
TO INPUT/OUTPUT (I/O)
BOX
Figure K-2: Benchmark Control Panel Rear View
