Benchmark 6000 DF Installation, Operation & Maintenance Manual
CHAPTER 8 – TROUBLESHOOTING GUIDE
Page 132 of 219
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913
OMM-0096_0B
03/21/2014
Ph.: 800-526-0288
GF-141
Figure 8-2: Pilot Burner & Flame Detector Locations
Figure 8-3: SSOV Actuator With Gas Pressure Adjustment (SKP25)
BRASS HEX HEAD
(Remove to access the
Gas Pressure Adjustment
Screw).
DAMPING ORIFICE
COVER SCREW
SIGHT GLASS
MAIN FLAME
DETECTOR
TO PILOT
GAS LINE
BLOWER
BLOWER FLANGE
BURNER PLATE
PILOT
BURNER
PILOT FLAME
DETECTORS (2 EA.)
