Benchmark 6000 DF Installation, Operation & Maintenance Manual
CHAPTER 7 – MAINTENANCE
OMM-0096_0B AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 115 of 219
GF-141
Ph.: 800-526-0288
03/21/2014
Air Filter Cleaning & Replacement Procedures
1. Set the ON/OFF switch on the control panel, to the OFF position. Disconnect AC power
from the unit.
2. Remove the front panel from the unit by grasping the handles and pulling outward.
3. Refer to Figure 7-11 and locate the air filters attached to the “Y” shaped duct connected to
the air/fuel valve inlet.
4. Using a flat-tip screwdriver or 5/16” nut driver, loosen the clamp securing the filter to the
“Y” duct at the air/fuel valve inlet. Remove the filter and clamp.
5. The filters may be cleaned in hot soapy water to remove oil and dirt. The filter should be
thoroughly dried and then sprayed with a light coating of oil, (NOT WD-40), prior to
reinstallation.
6. Each replacement air filter is equipped with its own clamp. Therefore, simply install the
replacement air filter on “Y” duct and tighten the clamp with a flat-tip screwdriver or 5/16”
nut driver.
7. Replace the front panel on the unit and return boiler to service use.
Figure 7-11. Air Filter Location and Removal
AIR FILTERS
AIR/FUEL VALVE
BLOWER
“Y” DUCT
AIR FILTER
CLAMPS
GAS TRAIN
