Benchmark 6000 DF Installation, Operation & Maintenance Manual
APPENDIX A – BOILER MENU DESCRIPTIONS
OMM-0096_0B AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 155 of 219
GF-141
Ph.: 800-526-0288
03/21/2014
APPENDIX A – BOILER MENU ITEM DESCRIPTIONS
MENU LEVEL & OPTION DESCRIPTION
OPERATING MENU
Active Setpoint This is the setpoint temperature to which the
control is set when operating in the Constant
Setpoint, Remote Setpoint or Outdoor Reset
Mode. When in the Constant Setpoint Mode, this
value is equal to the Internal Setpoint setting in the
Configuration Menu. When in the Remote
Setpoint Mode, this value is the setpoint equivalent
to the remote analog signal supplied to the unit.
When in the Outdoor Reset Mode, this is the
derived value from the charts in Appendix D.
Inlet Water Temp
Displays the inlet water temperature in ºF or ºC.
Default is ºF
Air Temp Air Temp is the air temperature at the input to the
Air/Fuel Valve. This reading is one of the
parameters used to control the Blower Motor
speed.
Outdoor Temp Outdoor temperature is displayed in ºF (default) or
ºC only if outdoor sensor is installed and enabled.
Valve Position In Desired input valve position. This would normally
be the same as the fire valve position shown on
the bargraph (valve position out) when the boiler is
operating.
Exhaust Temp Displays the exhaust temperature in °F (default),
or ºC.
Flame Strength Displays flame strength from 0% to 100%.
Oxygen Level Displays the real-time combustion oxygen (O
2
)
level (%) measured by the O
2
sensor.
Run Cycles Displays the total number of run cycles from 0 to
999,999.
Run Hours Displays total run time of unit in hours from 0 to
9,999,999.
Fault Log Displays information on the last 20 faults.
