• EC1 — Echo (Stereo Delay) 1

Although similar to the Mono Delay 1 program, the Echo (Stereo Delay) program features independent feedback settings for the ieft
and right channels.

FBDL

180.0

FBDR TYP

90.0 LPF

CutF FBL FBR

THRU +20 +20

FBLR FBRL INDLY

-30 +30 0.0

WID MIX LVL

10 60 0

FBDL (Left Channel Feedback Delay Time: 0.1 —
270.0msf
FBDR fRIaht Channel Feedback Delay Time: 0.1 —
270.0msl

These parameters independently set the delay time before
feedback begins for the left and right channels.

TYP (Feedback Filter Type: HPF. LPFf
Selects the type of feedback filter to be used with the Echo
(Stereo Delay) effect: HPF = high-pass filter; LPF = low-pass
filter. Please note that whenever the setting of this parameter
is changed, the "CutF" parameter, below, is automaticaily set

to "THRU".

FBL (Left Channel Feedback: -100 — +100 %1
FBR fRight Channel Feedback: -100 — +100 %)
Determine the amount of effect-sound feedback returned to

the input of the ieft- or right-channel processor. Negative
values produce out-of-phase feedback. Higher values

produce a greater number of repeats.

FBLR fLeft Channel Cross Feedback: -100 —+100%)
FBRL fRiaht Channel Cross Feedback: -100 — +100%!

The FBLR parameter determines the amount of effect-sound
feedback from the left chanel returned to the input of the

right-channel processor. The FBRL parameter works in hte

opposite direction — right-channei output to left-channel

Input.

INDLY fInitial Delay Time: 0.0 — lOOmsf
Sets the delay before the first repeat.

MIX fMixIna Balance: 0 —100%!
Sets the balance between the direct and effect sound. Higher
values produce a greater proportion of effect sound in relation

to direct sound.

LVL

fOutPUt

Level: -°

. -30 — +6dBl

Determines the output level of the EC1 effect.

CutF fFilter Cutoff Frequency: THRU. 160Hz —
I.OkHz/I.OkHz —11kHz. THRUt
Sets the cutoff frequency of the filter type selected in the
preceding parameter (TYP). If the HPF is selected, the range
is from 160Hz to 1 .OkHz. If the LPF is selected the range is

from 1.0kHz to 11kHz. In either case the "THRU" setting

bypasses the filter.
