• DST — Stereo Distortion/Equalizer
If you don't need the compression capabilities of the CDE or CDW effects, this effect offers a combination of distortion and
equalizer.
RO-
LO-
TRG—^
DISTORTION —{>
GATE
DST
GATE
CTRL
DISTORTION —
LPF
3
TT7
if-
LoG MIG MIG LVL
\ '
;!iF
' w
> :x>^ ---------- P>—OR
DST TRG LPF LVL
100 -45 7.0k 0
HIG fHlah Gain:-15 —4-15 dB)
Sets the amount of boost or cut applied to frequencies above
6.3 kHz.
LoG MiG MiF HiG
+2 -3 2.2k 0
Distortion
DST fDistortion Drive Level: 0 — 2001
Sets the degree of distortion produced. Higher values
produce more distortion.
TGR fNolse Gate Trigger Level: -80 -------- 30 dBt
Sets the threshold level of the distortion effect stage noise
gate. Refer to page 20.
LPF flow Pass Filter Cutoff Frequency: 500HZ — 16kHZ.
THRU!
Ckintrols the tone of the distortion sound. Refer to page 20.
LVL fOutPut Level: -°°. -30 — +6 dBt
Determines the output level of the DST effect.
Equalizer
LoG fLow Gain: -15 — +15 dBl
Sets the amount of boost or cut applied to frequencies below
280 Hz. Refer to page 20.
MIG fMId Gain: -15 — *15 dBt
Sets the amount of boost or cut applied to mid-band
frequencies.
MIF (Mid Frequency: 400 — 6.3 kHzl
Sets the center frequency of the Mid equalizer band.
