CONNECTION TO AN EXTERNAL TRAFFIC SOURCE
Zaon XRX - Serial Setup
CONFIGURATION OF THE ZAON XRX
To configure the Zaon XRX, perform the following steps:
•
Using the XRX AIRCRAFT menu, set the aircraft type as
appropriate for your aircraft as described in the ZAON users
Manual.
•
Using the XRX RANGE menu, set the horizontal detection range
to 6 nm radius.
•
Using the XRX ALTITUDE menu, set the altitude limitation to
2500 ft.
•
Using the XRX COM menu, set the third party communications
to PROFILE 1.
o Verify the XRX configuration switches are set as
described in the XRX Users Guide for third-party output.
•
Press Mute to return to the traffic screen. This screen will show
“PROFILE 1”.
•
Set the configuration switches on the Zaon XRX to the correct
configuration to use the RS-232 output.
CONFIGURATION OF AV8OR
To configure the AV8OR to receive external traffic data, perform the
following steps:
•
If the Weather Source is set to Serial , it must be changed to
Bluetooth or None.
•
From the Aviation Main Menu, tap the soft key to open
the System Setup Menu.
•
Highlight the Device Setup option and tap the SELECT soft key
to show the Device Setup page.
•
The AV8OR must be set up so that the Traffic Port is configured
as “
Serial” . The Type must be set as “ ZAON Traffic” .
o On the Device Setup page, the configuration steps are:
o Change any port that is set to “Serial” to either
“BlueTooth” or “None” as only one serial port is
available.
o On the Traffic row, set Port to “Serial”.
