Honeywell Bendix/King AV8OR Handheld User’s Guide
D200803000008 System Setup Function
Rev 5 Mar 2012 Page 2-157
© Honeywell International Inc. Do not copy without express permission of Honeywell
2. Drag the scroll bar to up and down to select the desired new
data field type. The abbreviation of the selected data type will be
displayed in the highlighted left data field window along with its
present value.
3. Tap and highlight the left data window, the new data window
configuration is completed.
4. Repeat 1 through 3 for each data field window to be changed.
5. Totally 21 data field types can be selected, they are:
•
BRG: Bearing to WPT
•
CDI: Deviation Indicator
•
DIS: Distance to WPT
•
DEP TIME: Departure Time
•
DTK: Desired Track
•
ESA: En Route Safe Altitude
•
ETA WPT: Est. Time Of Arrival
•
ETE WPT: Est Time En Route
•
FLT TIME: Flight Time
•
GNDSPD: Ground Speed
•
GPS ALT: GPS Altitude
•
MSA: Minimum Safe Altitude
•
NEAR POS: Near Position Display
•
PPOS: Present Position
•
STP WTCH: Stop Watch
•
TIME: Time
•
TKE: Track Angle Error
•
TRACK: Actual Track
•
TRAFFIC: Traffic Mini-Targets
•
TTS: Track to Steer
•
WPT: Active WPT
•
XTK: Cross Track Error
WIDE WINDOWS soft key controls the width of the data windows.
Tap the WIDE WINDOWS soft key to expand the width of the data
field windows to make long labels in the windows more readable.
The
WIDE WINDOWS soft key changes to NARROW WINDOWS
when the windows are set to WIDE WINDOWS as shown in the
figure below.
