Honeywell Bendix/King AV8OR Handheld User’s Guide
D200803000008 Auxiliary Function
Rev 5 Mar 2012 Page 2-143
© Honeywell International Inc. Do not copy without express permission of Honeywell
Tap the EDIT soft key to edit data on a highlighted cell. Enter the
weight and the arm in each field of the Envelope page. Use the scroll
bar to view any fields that are not visible on the screen.
Tap the FILE soft key to save the displayed Weight and Balance
data to a file.
CREATING A NEW WEIGHT AND BALANCE SECTION
Use the following order of entry to create a new Weight and Balance
section for an aircraft.
1. Select the Profile tab and enter data for all of the fields.
2. Select the Envelope tab and enter the weight and the arm for
the number of envelope points that was entered in the Profile
tab.
3. View the C.G. Graph page and the Layout page and make sure
that they match your aircraft flight manual Type Certificate.
4. Select the Data Entry Tab and enter the Arm for each row that
shows. (Rows were defined in the
Profile page)
5. Tap on the FILE soft key to save or create a new weight and
balance file. An Aircraft Profile pop up button shows. If no
Weight and Balance file has been created yet, only the
CLOSE
and the NEW FILE soft keys show. If a file has already been
created, SAVE , LOAD and DELETE soft keys also show.
6. Tap on the NEW FILE soft key and enter the name of the new
aircraft profile into the data entry screen. Tap on the “Enter” key
to accept the aircraft profile name.
7. Tap on the SAVE soft key and the OK soft key to save the new
aircraft profile.
Multiple Weight and Balance aircraft profiles can be created for
different aircraft. After the aircraft profiles are created, use the
FILE
soft key that shows on the “Data Entry”, “Profile” or “Envelope” tabs
on the Weight and Balance screen to display the “Aircraft Profile”
window. Select and highlight the aircraft profile you want to use and
tap on the
LOAD soft key to load that profile into the current settings.
