Honeywell Bendix/King AV8OR Handheld User’s Guide
D200803000008 System Setup Function
Rev 5 Mar 2012 Page 2-167
© Honeywell International Inc. Do not copy without express permission of Honeywell
•
The bit error rates drop down (the lower the better)
•
The service level displays on the page
•
The “Receiving Valid Data” goes green
•
The WX icon in the lower left hand status window displays the
signal strength.
The bars on the WX icon in the status window show the
strength of the incoming weather satellite signal.
•
Three bars indicates the strongest signal. All available WX
products will be received for the subscription level that has been
purchased.
•
Two bars indicates marginal reception. The NEXRAD weather
product may not be displayed.
•
One or no bars indicates that signal strength is too low to receive
weather product data.
Refresh Mode
NOTE: The REFRESH MODE soft key is only available when
“WxWorx” is set as the Weather Type on the Device Setup
Page.
The REFRESH MODE soft key provides the user with an easy
method to activate the WxWorx receiver.
Activation should only be necessary when the user is attempting to
use the receiver for the first time, the user has changed subscription
levels or the WxWorx receiver has become deactivated for any
reason.
To begin the activation process, the user either contacts WxWorx
technical support or uses their website. After all of the appropriate
data has been submitted or entered, the XM system will transmit an
activation message within the next 3 hours.
Tapping the REFRESH MODE soft key causes the AV8OR to send
commands to the WxWorx receiver that forces it into the activation
mode as long as the user remains on this page or taps the
NORMAL
MODE soft key. When a Service Level is displayed, the activation
has been successfully completed.
