Honeywell Bendix/King AV8OR Handheld User’s Guide
D200803000008 Appendix
Rev 5 Mar 2012
Page 6-7
© Honeywell International Inc. Do not copy without express permission of Honeywell
CONNECTION TO AN EXTERNAL GPS SOURCE
The AV8OR will accept external GPS source data via the RS 232
interface and can be used as a non-certified display of GPS data.
Below is a list of a few RS 232 GPS units that have been evaluated
Reminder: The AV8OR only provides for one RS 232 interface.
Bendix/King KLN-94
Garmin© GNS 430/430W/530/530W
To configure the AV8OR to receive external position and flight plan
data, perform the following steps:
From the Aviation Main Menu, tap the soft key to open the
System Setup Menu.
Highlight the
Device Setup option and tap the SELECT soft key to
show the Device and Port Setup page.
The AV8OR must be set up so that the Position Port is configured as
“Serial” and the Flight Plan Port is configured as “External”. The type
must be set as AR-NAV.
On the Device and Port Setup page, the configuration steps are:
•
If the Weather Source is set to Serial, it must be changed to
either
BlueTooth or None .
•
Set the Position Port to “ Serial ”.
•
Set the Flight Plan Port to “ External” .
•
Set the Position Type to “ AR-NAV ”. This will change the Flight
Plan Type to “ENH AR-NAV”.
When finished the Device and Port Setup page should look
like Figure 6-3.
