Page 155
Honeywell Bendix/King AV8OR Handheld User’s Guide
D200803000008 Weather
Function
Rev 5 Mar 2012
Page 2-115
©
Honeywell International Inc. Do not copy without express permission of Honeywell
Figure 2-162: WX – Legend Info
XM Overlays
The following additional XM services can be overlaid on the primary
pages:
•
Metar:
•
Graphical TFR Overlay
•
Lightning
•
Cloud Tops
Storm Cells
Overlays are configured in the Overlay Setup page in the Map Setup
section as shown in the figure below.
Figure 2-163: Topo On Map – Overlay Setup
