Honeywell Bendix/King AV8OR Handheld User’s Guide
D200803000008 System Setup Function
Rev 5 Mar 2012 Page 2-147
© Honeywell International Inc. Do not copy without express permission of Honeywell
The following are the general system setup options and their
possible values.
•
Aircraft Type : Select the appropriate host aircraft type: Fixed
Wing or Rotary Wing . This determines the aircraft symbol
that is used in VFR Moving Map mode.
•
Auto-Hide Keys on Map Page : When this option is turned
ON and a value in seconds is set, all the soft keys on the VFR
Moving Map page are automatically removed after the set
time delay. Touching on the screen makes the soft keys
visible again. If the option is set to OFF the soft keys are
always visible.
•
Flight Logging Rate : Sets the interval in seconds that the
system logs position data and loads it into a 2000-point cyclic
memory. The interval can be set between 1 and 99 seconds.
•
Position Coordinate System : Sets the coordinate system to
be used for the display and entry of position information. The
available options are:
o Lat/Long : (Latitude and longitude)
o OS (GB): Ordnance Survey Great Britain
o OS (Ireland): Ordnance Survey Ireland
o UTM : Universal Transverse Mercator
o MGRS : Military Grid Reference System.
•
Ellipsoid : Sets the datum to be used for the display and entry
of position information. The available options are:
o WGS84: the WGS84 datum
o OS (GB): Ordnance Survey Great Britain
o OS (Ireland): Ordnance Survey Ireland
o ED50 (Euro Mean): the ED50 datum
o NAD27 (CONUS): the NAD27 (CONUS) datum
•
Speed Units : Sets speed units to Knots (nautical miles per
hour), mph (statute miles per hour) or kph (kilometers per
hour).
•
Distance Units : Sets distance units to Nautical Miles ,
Statute Miles or Kilometers .
•
Altitude Units : Sets altitude units to Feet or Meters . When
feet are selected, all altitudes are reported in feet. When
meters are selected, all altitudes are reported in meters.
•
Runway Length Units : Sets runway length units to Feet or
Meters . When feet are selected, runway lengths are reported
in feet. When meters are selected, runway lengths are
reported in meters.
