Honeywell Bendix/King AV8OR Handheld User’s Guide
D200803000008
System Setup Function
Rev 5 Mar 2012
Page 2-155
©
Honeywell International Inc. Do not copy without express permission of Honeywell
•
Offset from UTC: If the user sets Time Zone as Local, the Offset
from UTC column can be configure. This method permits offsets
of hours and 30-minute increments.
•
Magnetic Variation: Settings are Auto or Manual. When set to
auto the magnetic variation is derived from the GPS location.
When set to manual the variation angle is entered in the line
below by moving the cursor to the left, then down and then to the
right to highlight the angle value field. The angle range is from 0
to 180 degrees.
•
Near Position Format: All Data, Airports / (Very high frequency
Omni-directional Radio range (VOR)s, or VORs Only.
•
Turn Anticipation: ON or OFF. Turn Anticipation assists
navigation for a fixed wing aircraft along a curved path segment
to ensure a smooth transition between two adjacent legs in the
flight plan using a standard rate turn.
•
SUA Buffer: The SUA altitude buffer is set from 500 to 16000
feet in 100-foot increments.
•
SUA Alerting: Special Use Airspace (SUA) Alerting is turned ON
or OFF. When SUA Alerting is turned on, a SUA alerting
message shows when the aircraft is within the SUA alert zone.
•
SUA Display Filtering: Special Use Airspace (SUA) Display
Filtering is turned ON or OFF.
•
VSD (Smart Profile) Swath Distance:
o
For Nm: 0.1 to 1.0 nm adjustable in 0.1 nm
increments, using the numeric keyboard (default =
0.5 nm)
o
For sm: 0.1 to 1.0 sm adjustable in 0.1 sm
increments, using the numeric keyboard (default =
0.6 sm)
o
For km: 0.2 to 2.0 km adjustable in 0.2 km
increments, using the numeric keyboard (default =
1.0 km)
•
VSD (Smart Profile) Above Aircraft
:
o
For Feet: 0500 to 2000 ft adjustable in 100 ft
increments using the numeric keyboard (default =
1000 ft)
o
For Meters: 150 to 600 .m adjustable in 50 m
