Table 9-16. ASCII Translation Table for BATSTATUS Data
Translating ASCII Status Data
ASCII Value
Bit 3
Bit 2
Bit 1
Bit 0
Use the table at right to evaluate the ASCII character
output for bytes 3 – 12 and determine which of the
low order bits are set on.
For example, if the Digital Output Status returned in
bytes 8 – 11 is AC@@, the table at right can be used
with the bit assignments described above to
determine that digital outputs 4, 7, and 8 are active:
• A (byte 8) indicates that DIGOUT 4 (bit 0) is on
• C (byte 9) indicates that DIGOUTs 7 and 8 (bits 1
and 0) are on
• @@ indicates that bytes 10 and 11 are not used
@
0
0
0
0
A
0
0
0
1
B
0
0
1
0
C
0
0
1
1
D
0
1
0
0
E
0
1
0
1
F
0
1
1
0
G
0
1
1
1
H
1
0
0
0
I
1
0
0
1
J
1
0
1
0
K
1
0
1
1
L
1
1
0
0
M
1
1
0
1
N
1
1
1
0
O
1
1
1
1
EDP Commands
