51 520 Indicator Installation Manual
9.1.2 Reporting Commands
Reporting commands (see Table 9-2) send specific
information to the EDP port. These commands can be
used in both setup mode and normal mode.
Table 9-2. EDP Reporting Commands
Command Function
DUMPALL List all parameter values
SPDUMP Print setpoint configuration
VERSION Write
520
software version
P Write current displayed weight with units
identifier. See Section 12.4 on page 74 for
more information.
S Write one frame of stream format
9.1.3 The RESETCONFIGURATION Command
The RESETCONFIGURATION command can be used
in setup mode to restore all configuration parameters to
their default values.
This command is equivalent to using the DEFAULT
function in TEST mode. See Section 12.3 on page 74
for more information about test mode.
Note
All load cell calibration settings are lost when
the RESETCONFIGURATION command is run.
9.1.4 Parameter Setting Commands
Parameter setting commands allow you to display or
change the current value for a particular configuration
parameter (Tables 9-3 through 9-12).
Current configuration parameter settings can be
displayed in either setup mode or normal mode using
the following syntax:
command
Most parameter values can be changed in setup mode
only; setpoint parameters listed in Table 11-2 on
page 69 can be changed when in normal weighing
mode.
Use the following command syntax when changing
parameter values:
command=value
where
value
is either a number or a parameter value.
Use no spaces before or after the equal (=) sign. If you
type an incorrect command, the display reads
??
.
For example, to set the motion band parameter to 5,
type the following:
MOTBAND=5D
For parameters with selectable values, enter the
command and equal sign followed by a question mark:
command=?
to see a list of those values. The indicator must be in
setup mode to use this function.
Table 9-3. CONFIG EDP Commands
Command Description Values
GRADS Graduations 1–9999999
ZTRKBND Zero track band OFF, 0.5D, 1D, 3D
ZRANGE Zero range 1.9%, 100%
MOTBAND Motion band 1D, 2D, 3D, 5D, 10D, 20D, OFF
OVRLOAD Overload FS+2%, FS+1D, FS+9D, FS
SMPRAT Sample rate 60HZ, 120HZ, 30HZ, 7.5HZ, 15HZ
DIGFLTR1
DIGFLTR2 Digital filtering 1, 2, 4, 8, 16, 32, 64, 128, 256
RATLTRAP Rattletrap filtering OFF, ON
DFSENS Digital filter cutout sensitivity 2OUT, 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
DFTHRH Digital filter cutout threshold NONE, 2DD, 5DD, 10DD, 20DD, 50DD, 100DD, 200DD, 250DD
PWRUPMD Power up mode GO, DELAY
TAREFN Tare function BOTH, NOTARE, PBTARE, KEYED
