Rice Lake 520 HMI Digital Weight Indicator Installation Manual User Manual
Page 60

EDP Commands
54
CK_TARGET
number
CK_UNDER
number
CK_UNDER_PCT
number
CK_ZBAND
OFF, 1D, 2D, 5D, 10D, 20D, 50D
ELEV.CAL
Displays the calibrated value for
elevation (view only).
ELEV.LOC
Enter the elevation value at your
current location (must be
changed to match the elevation at
the operating location if different
than the elevation at the initial
calibration site)
LAT.CAL
Displays the calibrated value for
latitude (view only).
LAT.LOC
Enter the latitude value at your
current location (will be changed
to match the latitude at the
operating site if different than the
latitude at the initial calibration site)
FBTRACK
Sets the update rate of the Field
bus cards (DeviceNet, Profibus,
Remote I/O)
LFT, IND
SPDECPTFMT
Allows the setpoint values to use a
decimal point or not
DECIMAL, NODECML
Command
Description
Values
Table 9-7. PROGRM EDP Commands (Continued)
