Table 9-8. SETPNTS EDP Commands
Command
Description
Values
SETPOINT
Setpoint number
1–8
KIND
Setpoint kind
OFF, GROSSSP, NETSP, +RELSP, –RELSP, %RELSP, PAUSE,
DELAY, WAITSS, COUNTER, AUTOJOG, COZ, INMOTON,
INRANGE, –GROSS, –NET, BATCHPR, TIMER, CONCUR
VALUE
Setpoint value
number
PSHTARE
Push tare
OFF, ON
PSHPRINT
Push print
OFF, ON, WAITSS
PSHACCM
Push accumulate
OFF, ON, ONQUIET
TRIP
Trip
HIGHER, LOWER, INBAND, OUTBAND
BANDVAL
Band value
number
HYSTER
Hysteresis
number
ALARM
Alarm
OFF, ON
PREACT
Preact
OFF, ON, LEARN, FLOW
PREVAL
Preact value
number
PREADJ
1-100%
PRESTAB
0-65535
PREBAND
number
PRECOUNT
1-65335
BATCH
Batch enable
OFF, ON
BATSTART
Batch step enable
See Section 11.0 on page 65 for detailed information
BATPAUSE
Batch step pause
BATRESET
Batch step reset
BATSTATUS
Batch status
NAME
Setpoint name number
NONE, 1–8
ACCESS
Setpoint access
OFF, ON, HIDE
DIGOUT
Digital output
NONE, 1–4
RELNUM
Relative setpoint number
1–8
START
Starting setpoint
1–8
END
Ending setpoint
1–8
BATCHNG
Batching mode
OFF, AUTO, MANUAL
Table 9-9. PFORMT EDP Commands
Command
Description
Values
GFMT
Gross demand print format string
See Section 10.2 on page 62 for detailed information
NFMT
Net demand print format string
CFMT
Count format string
SPFMT
Setpoint print format string
EDPFMT
EDP demand print format string
HDRFMT
Ticket header format string
STRMFMT
Custom stream format string
55
