39 520 Indicator Installation Manual
3.2.9 Analog Output Menu
The ALGOUT menu is used only if the analog output option is installed. If the analog output option is installed,
configure all other indicator functions and calibrate the indicator before configuring the analog output. See
Section 12.12 on page 86 for analog output calibration procedures.
9999999 9999999 "-(065 %*(*/ 4&5154 9999999 130(3. 1'03.5 4&3*"- $"-*#3 9999999 $0/'*( '03."5
4063$&
(3044
0''4&5 &33"$5
'6--4$
)0-% OVNCFS
.*/
OVNCFS
."9 58;&30
/&5
5841"/
;&304$
9999999 7&34
OVNCFS OVNCFS
.*/ /&( ."9/&(
0/
0''
0/
0''
Figure 3-17. Analog Output Menu
Table 3-9. Analog Output Menu Parameters
ALG OUT Menu
Parameter Choices Description
Level 2 submenus
SOURCE1 GROSS
NET Specifies the source tracked by the analog output.
OFFSET 0%
20% Zero offset. Selects whether the analog output supplies voltage (0–10 V) or current (4–20 mA)
output. Select 0% for 0–10 V output; select 20% for 4–20 mA output.
ERRACT FULLSC
HOLD
ZEROSC Error action. Specifies how the analog output responds to system error conditions.
Possible values are:
FULLSC: Set to full value (10 V or 20 mA)
HOLD: Hold current value
ZEROSC: Set to zero value (0 V or 4 mA)
MIN 0.000000
number Specifies the minimum weight value tracked by the analog output. Specify a value in the range
0–9999999.
MIN NEG OFF
ON The analog output can be set to track negative scale weight values.
MAX 10000.00
number Specifies the maximum weight value tracked by the analog output. Specify a value in the range
0–9999999
MAX NEG OFF
ON The analog output can be set to track negative scale weight values.
TWZERO 0000020
number Tweak zero. Adjust the analog output zero calibration. Use a multimeter to monitor the analog
output value. Press and hold
or to adjust the output.
TWSPAN 0062040
number Tweak span. Adjust the analog output span calibration. Use a multimeter to monitor the analog
output value. Press and hold
or to adjust the output.
3.2.10 Version Menu
The VERS menu is used to check the software version installed in the indicator. There are no parameters associated
with the Version menu: when selected, the indicator displays the installed software version number.
9999999 9999999 9999999
4PGUXBSF
WFSTJPO
7&34 "-(065 %*(*/ 130(3. 1'03.5 4&3*"- $"-*#3 $0/'*( '03."5 4&5154
Figure 3-18. Version Menu
