Configuration
32
PROMPTS
PRMPT1–
PRMPT8
Specify prompts for use in setpoint names (up to 16 characters). Prompts are referenced by
the NAME parameter under the SETPTS submenus; prompts appear in the secondary display
area during setpoint execution for batch type setpoints.
REGULAT
NTEP
CANADA
NONE
OIML
Regulatory mode. Specifies the regulatory agency having jurisdiction over the scale site.
• OIML, NTEP, and CANADA modes allow a tare to be acquired at any weight greater than
zero. NONE allows tares to be acquired at any weight value.
• OIML, NTEP, and CANADA modes allow a tare to be cleared only if the gross weight is at
no load. NONE allows tares to be cleared at any weight value.
• NTEP and OIML modes allow a new tare to be acquired even if a tare is already present.
In CANADA mode, the previous tare must be cleared before a new tare can be acquired.
• NONE, NTEP and CANADA modes allow the scale to be zeroed in either gross or net
mode as long as the current weight is within the specified ZRANGE. In OIML mode, the
scale must be in gross mode before it can be zeroed; pressing the ZERO key in net mode
clears the tare.
The value specified for this parameter affects the function of the front panel TARE and ZERO
keys. See Section 12.5 on page 75 for a complete description of TARE and ZERO key
functions for each of the regulatory modes.
REGWORD
GROSS
BRUTTO
Regulatory word for GROSS. Specifies GROSS or BRUTTO.
NEG NET
ON
OFF
SETPT
DECIMAL
NODECML
Sets whether the setpoint values use a decimal point or not.
BUS
LFT
IND
Sets the update rate of the Field Bus cards.
Level 3 submenus
DATEFMT
MMDDYY
DDMMYY
YYMMDD
Specifies the format used to display or print the date.
DATESEP
SLASH
DASH
SEMI
Specifies the date separator character.
DATESET
nnnnnn
Enter date specified by the DATEFMT parameter.
TIMEFMT
12HOUR
24HOUR
Specifies the format used to display or print the time.
TIMESEP
COLON
COMMA
Specifies the time separator character.
TIMESET
nnnnnn
Enter time specified by the TIMEFMT parameter.
ABS
UNDER
OVER
CKZBAND
CKPRINT
Select checkpoints by giving absolute minimum and maximum weight values in primary units.
PERCENT
TARGET
UNDER
OVER
CKZBAND
CKPRINT
Select a target weight in primary units and enter the under/over values as a percent of the
target. Specify values as a whole percent. Default is 10%.
ACCESS
DISABLE
ENABLE
Operator access to piece count mode. Specify DISABLE if piece count mode will not be used.
With access disabled, pressing the GROSS/NET (MODE) key toggles between gross and net
modes only.
PROGRM Menu
Parameter
Choices
Description
Table 3-6. Program Menu Parameters (Continued)
