Table 9-10. DIG OUT EDP Commands
Command Description
DON#nn Set digital output nn on (active)
DON#0 Set all digital outputs on (active)
DOFF#nn Set digital output nn off (inactive)
DOFF#0 Set all digital outputs off (inactive)
For commands ending with “#nn”, nn is the digital output (1-4) being set on or off.
Table 9-11. DIG IN EDP Commands
Command Description Values
DIGIN1
DIGIN2
DIGIN3 Digital input function OFF, ZERO, NT/GRS, TARE, UNITS, PRINT, ACCUM, DSPTAR,
ENTER, BATRUN, BATSTRT, BATPAUS, KBDLOC, HOLD, CLRCN,
GROSS, NET, PRIM, SEC, TIME, DATE, CLRTAR, CLRACC
Table 9-12. ALGOUT EDP Commands
Command Description Values
SOURCE1 Analog output source GROSS, NET
OFFSET Zero offset 0%, 20%
ERRACT Error action FULLSC, HOLD, ZEROSC
MIN Minimum value tracked 0–9 999 999
MAX Maximum value tracked 0–9 999 999
ZERO1 Zero calibration 0–99999
SPAN1 Span calibration 0–99999
EDP Commands 56
