Table 9-4. FORMAT EDP Commands
Command Description Values
PRI.DECPNT Primary units decimal position 8.888888, 88.88888, 888.8888, 8888.888, 88888.88, 888888.8,
8888888, 8888880, 8888800
PRI.DSPDIV Primary units display divisions 1D, 2D, 5D
PRI.UNITS Primary units LB, KG, G, OZ, TN, T, GN, LT, NONE
SEC.DECPNT Secondary units decimal position 8.888888, 88.88888, 888.8888, 8888.888, 88888.88, 888888.8,
8888888, 8888880, 8888800
SEC.DSPDIV Secondary units display divisions 1D, 2D, 5D
SEC.UNITS Secondary units LB, KG, G, OZ, TN, T, GN, LT, NONE
SEC.MULT Secondary units multiplier 0.00000–99999.99
DECFMT Decimal format DOT, COMMA
DSPRATE Display rate 250MS, 500MS, 750MS, 1SEC, 1500MS, 2SEC, 2500MS, 3SEC,
4SEC, 6SEC, 8SEC
Table 9-5. CALIBR EDP Commands
Command Description Values
WVAL Test weight value test_weight_value
WLIN.F1–WLIN.F5 Actual raw count value for linearization points 1–5 —
WLIN.V1–WLIN.V5 Test weight value for linearization points 1–5 test_weight_value
WLIN.C1–WLIN.C5 Calibrate linearization points 1–5 —
WLIN.M1–WLIN.M5 Millivolt value for linearization points 1–5 test_weight_value
WLIN.W1–WLIN.W5 Working calibration values —
LC.CD Set deadload coefficient value
LC.CW Set span coefficient value
WK.CD Working deadload coefficient —
WK.CW Working span coefficient —
MV.CD Millivolt calibration value —
MV.CW Millivolt span calibration value —
EDP Commands 52
Command Description Values
EDP.BAUD EDP port baud rate 300, 600, 1200, 2400, 4800, 9600, 19200
EDP.BITS EDP port data bits/parity 8NONE, 7EVEN, 7ODD
EDP.TERMIN EDP port termination character CR/LF, CR
EDP.EOLDLY EDP port end-of-line delay 0–255 (0.1-second intervals)
EDP.HANDSHK EDP port handshaking OFF, ON
EDP.ADDRESS EDP port RS-485 address 0, 01–255
EDP.STREAM EDP port streaming OFF, LFT, IND
EDP.FORMAT EDP port stream format DEFAULT8, CUSTOM, BUS FMT, DEFAULT7
PRN.BAUD Printer port baud rate 300, 600, 1200, 2400, 4800, 9600, 19200
PRN.BITS Printer port data bits/parity 8NONE, 7EVEN, 7ODD
PRN.TERMIN Printer port termination character CR/LF, CR
PRN.EOLDLY Printer port end-of-line delay 0–255 (0.1-second intervals)
Table 9-6. SERIAL EDP Commands
