Adding and Replacing Parts
217
23 Remove the system board, slowly easing the connectors out of their access
holes on the back and side of the computer base:
a With the back of the computer facing you, grasp the upper-right
corner of the system board and lift it slightly.
b Pull the system board assembly away from you toward the front of the
computer and slightly to the right; at the same time, use your left
hand to release the audio connectors by pulling the side of the
computer base slightly to the left.
1 system board M2.5 x 5-mm screws (4)
