192
Adding and Replacing Parts
Replacing the FCM
1 Align the flash card module with the top of the system board and gently
snap it into place.
2 Replace the M2.5 x 5-mm screw on the top of the flash card module.
3 Replace the display assembly (see "Replacing the Display Assembly" on
page 179).
4 Replace the keyboard (see "Keyboard" on page 174).
5 Replace the hinge cover (see "Replacing the Hinge Cover" on page 174).
6 Replace the optical drive (see "Optical Drive" on page 158).
Palm Rest
CAUTION:
Only trained service technicians are authorized to remove or replace
the component covered by the following procedure. See your Product Information
Guide for complete information about safety precautions, working inside the
computer, and protecting against electrostatic discharge.
1 FCM 2 screw
1
2
