198
Adding and Replacing Parts
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as the
back panel) on the computer.
NOTICE:
To help prevent damage to the system board, remove the main battery
(see "Before Working Inside Your Computer" on page 156) before working inside the
computer.
1 Follow the instructions in "Before Working Inside Your Computer" on
page 156.
2 Remove the hinge cover (see "Removing the Hinge Cover" on page 173).
3 Remove the keyboard (see "Keyboard" on page 174).
4 Remove the display assembly (see "Removing the Display Assembly" on
page 176).
5 Remove the palm rest (see "Removing the Palm Rest" on page 193).
6 Disconnect the USB-port-board cable connector from the system board.
7 Remove the
M2.5 x 5-mm s crew, and lift the board out of the computer.
