Wrinkled/Stained paper
Action Yes No
1 Locate the cause of the problem using the Pitch
Configuration Chart.
a Launch the Tool Box, and click Chart Print
on the Diagnosis tab.
b Click the Pitch Configuration Chart button.
The Pitch Configuration Chart is printed.
Does the output match with the pattern for auger
mark?
Go to action 2. Contact Dell.
2 Execute the Clean Developer.
a Launch the Tool Box, and click Clean
Developer on the Diagnosis tab.
b Click the Start button.
c After you execute the Clean Developer, click
Chart Print on the Diagnosis tab.
d Click the Pitch Configuration Chart button.
The Pitch Configuration Chart is printed.
Does this solve your problem?
The task is
complete. Go to action 3.
3 Replace the PHD unit if you have a spare unit.
See "Replacing the Print Head Device (PHD)
Unit" and "Installing a PHD Unit."
Does this solve your problem?
The task is
complete. Contact Dell.
