Dell 2155cn/cdn Color Laser Printer - Manual (Page 79)

Installing Optional Accessories 77
5 Press button until Wireless Setup is highlighted, and then press the
(Set) button.
6 Press button until WPS is highlighted, and then press the (Set) button.
7 Ensure that Push Button Control is highlighted, and then press the
(Set) button.
8 Press button until Start is highlighted, and then press the (Set)
button.
9 Ensure that the message Please wait Wireless Setting is
displayed, and start the WPS-PBC on the wireless LAN access point
(Registrar), within two minutes of the step 7 operation.
NOTE: For WPS operation on the wireless LAN access point, refer to the
manual supplied with the wireless LAN access point.
10 When the WPS operation is successful and the printer is rebooted, wireless
LAN connection setting is completed.
Operator Panel
1 Press the (Menu) button.
2 Press button until System Setup is highlighted, and then press the
(Set) button.
3 Press button until Admin Menu is highlighted, and then press the
(Set) button.
4 Press button until Network is highlighted, and then press the (Set)
button.
5 Press button until Wireless Setup is highlighted, and then press the
(Set) button.
6 Ensure that Manual Setup is highlighted, and then press the (Set)
button.
7 Enter the SSID, and then press the (Set) button.
8 Select the network mode from Infrastructure and Ad-hoc
depending on your environment.
When you select Infrastructure, proceed to step 9.
When you select Ad-hoc, proceed to step 10.
9 Select the encryption type from No Security, WEP (64Bit), and WEP
(128Bit).
