64 Installing Optional Accessories
2 Select Available for the optional 250-sheet feeder setting.
3 Click Apply, and then click OK.
4 Close the Printers and Faxes(, Printers, or Devices and Printers) dialog
box.
Installing the Optional Wireless Adapter
The wireless adapter allows you to use the printer with wireless network
connection.
The specifications of the wireless adapter are described below.
NOTE: When the wireless adapter is installed, you cannot use IEEE 802.1x
authentication and/or the Ethernet port for a wired connection.
Item Specification
Connectivity Technology Wireless
Compliant Standards IEEE 802.11b, 802.11g, and 802.11n
Bandwidth 2.4 GHz
Data Transfer Rate IEEE 802.11n: 65 Mbps
IEEE 802.11g: 54, 48, 36, 24, 18, 12, 9, and 6 Mbps
IEEE 802.11b: 11, 5.5, 2, and 1 Mbps
Security 64 (40-bit key)/128 (104-bit key) WEP,
WPA- PSK (TKIP, AES), WPA2-PSK (AES)
(IEEE 802.1x attestation function of WPA 1x non-
corresponds)
Wi-Fi
®
Protected Setup
(WPS)
Push-Button Configuration (PBC),
Personal Identification Number (PIN)
