5. Replace the display assembly (see
258H
Installing the Display Assembly).
6. Replace the keyboard (see
259H
Keyboards).
7. Replace the media bay device (see
260H
XBay Devices).
8. Replace the hinge cover (see
261H
Installing the Hinge Cover).
22 System Board
22.1 Removing the System Board
CAUTION: Before working inside your computer, follow the safety instructions in the
XFR D630 Product Information Guide and in the XFR D630 User’s Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by
periodically touching an unpainted metal surface (such as a connector on the back of the
computer).
The system board's BIOS chip contains the Service Tag, which is also visible on a barcode label on the
bottom of the computer. The replacement kit for the system board includes a CD that provides a utility
for transferring the Service Tag to the replacement system board.
1. Follow the instructions in
262H
Before You Begin.
2. Remove the hard disk drive (see
263H
Hard Drive).
3. Remove the hinge cover (see
264H
Removing the Hinge Cover).
4. Remove the keyboard (see
265H
Keyboards).
5. Remove any installed media bay device (see
266H
XBay Devices).
6. Remove the memory module(s) (see
267H
Memory).
7. Remove the palm rest (see
268H
Removing the Palm Rest).
8. Remove any installed wireless communications cards (see
269H
WWAN, FCM & SIM Cards,
270H
Wireless
Local Area Network (WLAN) Cards,
271H
Internal Card with Bluetooth® Wireless Technology).
9. Remove the modem (see
272H
Removing the Modem).
9. Remove the speaker (see
273H
Removing the Speaker).
10. Remove the PC Card reader (see
274H
Removing the PC Card Cage).
11. Remove any installed smart cards or smart card blanks from the smart card slot.
