Dell TM XFR D630 Fully Rugged Notebook Service Manual
Page 73 of 106 Revision A01
7. Install the keyboard (see
150H
Keyboards).
8. Install the hinge cover (see
151H
Installing the Hinge Cover).
12.2 Flash Cache Module
CAUTION: Before you begin any of the procedures in this section, follow the safety
instructions in the XFR D630 Product Information Guide and in the XFR D630 User’s
Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by
periodically touching an unpainted metal surface (such as a connector on the back of the
computer).
NOTE: The WWAN card slot is located on the left center, next to the keyboard connector. The
FCM is installed into the WWAN card slot.
12.2.1 Removing the Flash Cache Module
1. Follow the procedures in
152H
Before You Begin.
2. Remove the hinge cover (see
153H
Removing the Hinge Cover).
3. Remove the keyboard (see
154H
Keyboards).
