Dell TM XFR D630 Fully Rugged Notebook Service Manual
Page 9 of 106 Revision A01
18815 XFR LCD ASSY TOUCH SCREEN 4
18802 PALMREST ASSY 11
18043 ASSY HANDLE WITH HOLDER 2
18619 LCD LATCH ASSY 2
18416 SCR,M3X14,PHH,MSCR,ZPS,XFR
8
18044 ASSY HANDLE 6
18824 SHOULDER STRAP ASSY 2
18417 PAN HEAD SCREW M2 X 12 -BLACK
7
18815 XFR LCD ASSY TOUCH SCREEN 7
18419 PAN HEAD SCREW M2.5 X 4 -BLACK
12
18810 HDD DOOR ASSY 4
18813 RJ DOOR ASSY 3
18814 USB PLASTIC DOOR ASSY 1
18034 FAN ASSY 3
9999-8024 PCMCIA HOLDER 1
18420 PAN HEAD SCREW M2.5 X 14 -BLACK
1
18802 PALMREST ASSY 1
18423 CSK SCREW M2 X 5 -BLACK 22
