Dell TM XFR D630 Fully Rugged Notebook Service Manual
Page 58 of 106 Revision A01
12. Lift the display assembly out of the base.
NOTE: The display grommets only need to be removed if you are replacing the display assembly
or replacing the display top cover assembly. The replacement kit will contain the grommet tool
that you need to perform the following steps. If your replacement kit does not contain the
grommet tool, do not perform the following steps.
Grommet tool
13. Follow these steps to remove the grommets from the left and right side of the display
assembly.
Location of left and right display grommets
a. To remove the right side grommet:
i. Lift and slide the grommet partially down the set of antenna cables
ii. Slide the ends of the grommet tool into the end of the grommet
