104
Airport Arrival Page
The airport arrival page shows the available Airport Standard Terminal Arrival (STAR)
procedures for the selected airport. Where multiple transitions or runways are associ-
ated with the arrival procedure, that information may also be displayed. A map image
provides a layout diagram for each arrival, transition and runway.
To scroll through the available arrivals:
1. Press the small right knob (
r
) to activate the cursor.
2. Rotate the large right knob (
d
) to place the cursor on the arrival (ARVL) procedure name
field.
3. Rotate the small right knob (
a
) to display a window of available arrivals for the selected air-
port. Continue rotating the small right knob (
a
) to select the desired arrival.
4. Press
E
. The cursor moves to the transitions (TRANS) field.
5. Rotate the small right knob (
a
) to display a window of available transitions. Continue rotating
the small right knob (
a
) to select the desired transition.
6. Press
E
. The cursor moves to the runway field.
{continued}
Arrival Procedure
Name
Airport Identifier,
Symbol and Type
Map Image
Fifth Page
in WPT group
Transitions
Runways Associated
with Arrival
WPT PAGES
Airport Arrivals
6
