EZ-SCREEN
Instruction Manual
Cascadeable EZ-SCREEN
Defined Area
Height*
30 mm Resolution Cascadeable Models
†
0.1 m to 18 m (4" to 60') range
Emitter (8-pin) Receiver
Emitter/Receiver
Pair
Number of
Beams
Response
Time (Tr)
300 mm (11.8") SLSCE30-300Q8 8SLSCR30-300Q8 SLSCP30-300Q88 20 11 ms
450 mm (17.7") SLSCE30-450Q8 SLSCR30-450Q8 SLSCP30-450Q88 30 13 ms
600 mm (23.6") SLSCE30-600Q8 SLSCR30-600Q8 SLSCP30-600Q88 40 15 ms
750 mm (29.5") SLSCE30-750Q8 SLSCR30-750Q8 SLSCP30-750Q88 50 17 ms
900 mm (35.4") SLSCE30-900Q8 SLSCR30-900Q8 SLSCP30-900Q88 60 19 ms
1050 mm (41.3") SLSCE30-1050Q8 SLSCR30-1050Q8 SLSCP30-1050Q88 70 21 ms
1200 mm (47.2") SLSCE30-1200Q8 SLSCR30-1200Q8 SLSCP30-1200Q88 80 23 ms
1350 mm (53.1") SLSCE30-1350Q8 SLSCR30-1350Q8 SLSCP30-1350Q88 90 25 ms
1500 mm (59.0") SLSCE30-1500Q8 SLSCR30-1500Q8 SLSCP30-1500Q88 100 27 ms
1650 mm (65.0") SLSCE30-1650Q8 SLSCR30-1650Q8 SLSCP30-1650Q88 110 30 ms
1800 mm (70.9") SLSCE30-1800Q8 SLSCR30-1800Q8 SLSCP30-1800Q88 120 32 ms
1950 mm (76.8") SLSCE30-1950Q8 SLSCR30-1950Q8 SLSCP30-1950Q88 130 34 ms
2100 mm (82.7") SLSCE30-2100Q8 SLSCR30-2100Q8 SLSCP30-2100Q88 140 36 ms
2250 mm (88.6") SLSCE30-2250Q8 SLSCR30-2250Q8 SLSCP30-2250Q88 150 38 ms
2400 mm (94.5") SLSCE30-2400Q8 SLSCR30-2400Q8 SLSCP30-2400Q88 160 40 ms
7.3 Cascadeable Emitter and Receiver Models – 30 mm Resolution
For cabling options, see Section 2.3.
Machine interface/power cables (one per end sensor, two per pair): Use QDE-..D cables.
Sensor interconnect cables (one per cascaded sensor, two per pair): Use DEE2R-..D cables.
*150 mm SLSC .. systems not available.
† Only standard 8-pin QD models are listed; 8-pin emitters/receivers feature “swapable” hookup; see Sections 3.3 and 3.7.
For other models:
5-pin emitters with Test input: Replace suffix “Q8” with “Q5”, (e.g., SLSCE30-150Q5), and
for the pair replace “Q88” with “Q85” (e.g., SLSCP30-150Q85).
Important: If a 5-pin emitter is used in the first (“master”) position in a cascaded system, then
5-pin emitters must be used in all other positions in that cascade.
Pigtail QD (8-pin models only): Replace the “Q” in the model number with “P” (e.g., SLSCE30-150P8).
ESD-safe models: Add “N” to the model number, prior to the QD option designation (e.g., SLSCE30-150NQ8). ESD-safe models are
not available with the pigtail QD option.
Op tional housing finishes: Prior to the QD designation in the model number,
add “A” for a clear (brushed) anodized aluminum finish, black endcaps (e.g., SLSCE30-150AQ8),
add “S” for a nickel-plated (“silver”) finish, black endcaps (e.g., SLSCE30-150SQ8),
add “B” for a black painted finish, black endcaps (e.g., SLSCE30-150BQ8),
add “W” for a white painted finish, black endcaps (e.g., SLSCE30-150WQ8), or
add “SO” for a “safety orange” painted finish, black endcaps (e.g., SLSCE30-150SOQ8).
